configuration options
procedure for changing, 3-11
tables
Alarm, C-16
General, C-9
Network Interface, C-7
Port, C-2
SNMP, C-19
User Interface, C-10
connectors, rear panel
functional description, 1-3
pin assignments, D-1
CPU failure message, 4-2
crossover cable, D-11
CSS (Controlled Slip Seconds) report, 4-8
Ctrl (Control) branch, examples of use, 3-9, 3-36,
3-39, 3-40, 4-10
Cust1 (Customer 1) configuration area, functional
description, 3-11
Cust2 (Customer 2) configuration area, functional
description, 3-11
cyclic redundancy check (CRC), error indication, 4-7
D
data channel loopback (DCLB), 4-23, C-3
data port, RS–232–like MIB, E-1
data terminal loopback (DTLB), 4-24, C-3
database, SNMP, 1-2
default configuration options, C-1
DevFail (Device Failure) message, 4-4
how to clear, 4-4
DevHS (Device Health and Status) branch, example of
use, 4-3
Device fail, self–test message, 4-2
Dial Out Delay Time, C-17
Dial–in Access, C-10
Download failed, Device Health and Status message,
4-4
DSU Operational, Device Health and Status message,
4-4
DTR, Ignore DTR configuration option, C-14
E
EDL, 1-2
configuration option, C-4
Mgmt Link configuration option, C-6
EER (Excessive Error Rate) condition
ASCII terminal/printer message, 4-11
Device Health and Status message, 4-4
front panel LED indication, 3-5
Performance Report message, 4-9
troubleshooting, 4-14
EER at Prt1, Device Health and Status message, 4-4
EIA–530–A interface, D-3
Embedded Data Link (EDL), 1-2
configuration option, C-4, C-6
used with SNMP system, F-1
enterprise–specific trap, enabling and disabling, C-24
enterprise-specific traps
description, 4-12
list of supported, 4-13
Err Rate, configuration option, C-5
ES (Errored Seconds) report, 4-7
Excessive Error Rate Threshold, C-18
external modem interface, D-11
F
Facility Data Link (FDL), 1-2
configuration option, C-7
used with SNMP system, 1-2, F-2
Fact1 (Factory 1) configuration area, functional
description, 3-11
Fact2 (Factory 2) configuration area, functional
description, 3-11
failure analysis, 4-14
failure message
during power-up self-test, 4-4
troubleshooting, 4-15
Far–End Performance Statistics, C-6
features, 1-1– 1-4
framing configuration option, C-7
Front Panel Emulation
functional description, 1-2, 3-1, G-1
installation and operation, G-1
