SNMP MIB Objects
E-24
3166-A2-GB20-10
November 1998
Table E-1.
SNMP MIB to Front Panel Command Cross-Reference (3 of 4)
Front Panel Command
SNMP MIB Object
Test–>Lpbk–>DCLB–>Prt
n
Test–>Lpbk–>Abort–>DCLB–>Prt1
Set IfExtnsTestType for Port 1
to testFullDuplexLoopBack
Set dsx1LoopbackConfig for Port 1
to noTest
Test–>Lpbk–>DTLB–>Prt
n
Test–>Lpbk–>Abort–>DTLB–>Prt1
Set IfExtnsTestType for Port 1
to testLoopDTLB
Set dsx1LoopbackConfig for Port 1
to noTest
Test–>Ptrns–>Send–>QRSS–>NET
Test–>Ptrns–>Abort–>Send–>NET
Set dsx1SendCode for Net T1 to
dsx1SendQRSS
Set dsx1SendCode for Net T1 to
dsx1SendNoCode
Test–>Ptrns–>Send–>QRSS–>Prt1
Test–>Ptrns–>Abort–>Send–>Prt1
Set IfExtnsTestType for Port
1 to testSendQRS
Set IfExtnsTestType for Port
1 to noTest
Test–>Ptrns–>Send–>1in8
Test–>Ptrns–>Abort–>Send–>NET
Set dsx1SendCode for Net T1 to
dsx1SendOtherTestPattern
Set dsx1SendCode for Net T1 to
dsx1SendNoCode
Test–>Ptrns–>Send–>511–>Prt1
Test–>Ptrns–>Abort–>Send–>Prt1
Set IfExtnsTestType for Port 1
to testSend511
Set IfExtnsTestType for Port 1
to noTest
Test–>Ptrns–>Mon–>QRSS–>NET
Test–>Ptrns–>Abort–>Mon–>NET
Set ifExtnsTestType for Net T1 to
testMonQRSS
Set ifExtnsTestType for Net T1 to
noTest
Test–>Ptrns–>Mon–>QRSS–>Prt1
Test–>Ptrns–>Abort–>Mon–>Prt1
Set ifExtnsTestType for Port 1
to testMonQRSS
Set ifExtnsTestType for Port 1
to noTest
Test–>Ptrns–>Mon–>511–>Prt1
Test–>Ptrns–>Abort–>Mon–>Prt1
Set ifExtnsTestType for Port 1
to testMon511
Set ifExtnsTestType for Port 1
to noTest
Cnfig–>Load Cnfig–>Save
Set devConfigAreaCopy to the desired choice (Active to
Customer1, etc.)
Cnfig–>Activ–>Edit–>Port–>Prt1->Port Type
Display rs232PortType for Port 1 to
rs422 or v35
Cnfig–>Activ–>Edit–>Port–>Prt1–>TxClock
Set/Display rs232SyncPortClockSource for Port 1 to
internal
or
external
Cnfig–>Activ–>Edit–>NET–>NET Framing
Set/Display dsx1LineType for NET T1 to
dsx1ESF or dsx1D4
Cnfig–>Activ–>Edit–>NET–>NET Coding
Set/Display dsx1LineCoding for NET T1 to
dsx1B8ZS or
dsx1AMI
Cnfig–>Activ–>Edit–>NET–>ANSI PRM
Cnfig–>Activ–>Edit–>NET–>Mgmt Link
Set/Display dsx1Fdl for NET T1 to
dsx1Ansi–T1– 403 or
dsx1Att–54016 or dsx1other
Cnfig–>Activ–>Edit–>Chan–>Prt1–>Assign To
Cnfig–>Activ–>Edit–>Chan–>Display
Set/Display dsx1FracNumber and dsx1Fracifindex for Net T1
Cnfig–>Activ–>Edit–>Chan–>Prt1–>Port Rate
Display rs232PortInSpeed or rs232PortOutSpeed for Port 1
Cnfig–>Activ–>Edit–>Gen–>Clock Src
Display dsx1TransmitClockSource for NET T1
