Appendix C Operation
Position The Paper Out Sensor
Figure 33. The Paper Out Sensor
The paper out sensor indicates when the printer runs out of paper. (The
sensor does not work with black backed forms.) Unlike the standard pedestal
printer, the ZTP requires you to load the paper through the paper out sensor
slot (Figure 30 and Figure 33). Correct positioning of the paper out sensor
ensures that the last form the printer prints will be properly presented to the
tear bar. To position the paper out sensor, do the following:
1. Position the paper properly at the tear bar (page 179).
2. Loosen the paper out sensor by turning the sensor knob
counterclockwise.
3. Position the paper out sensor so that there are at least 2 inches between
a perforation and the top of the paper out sensor.
4. Tighten the paper out sensor by turning the sensor knobs clockwise.
5. Press ONLINE/CLEAR. When the first print job is sent to the printer, the
paper is drawn into the printer, the top of form aligns with the print station,
and the print job begins.
Sensor Knob
Paper Out Sensor
Paper
Perforation
At least 2 inches
