174
Appendix C Performance Limitations
NOTE: If you use forms outside these limits, the print quality may not be
optimum, the printer may lose top-of-form, the frequency of paper
jams.
Paper Jams
Printer jams can occur if you tear off the form incorrectly. If you experience
two or more paper jams per box of forms, follow these guidelines to help
reduce jams:
• Position the lower paper guides properly
• Align the paper web tightness properly
• Position the form perforation against the tear bar
• Time the tear, while the paper is not moving
• Direct the tear force toward the user and across the tear bar, not upward.
User Environment
The ZTP is noisier than the standard pedestal printer because the forms exit
the printer out of the top of the pedestal lid.
Table 13. Forms Type
Description Length
Width
(edge to edge)
One to three part, continuous, with carbon, fan-folded,
edge-perforated paper forms 3 to 12 inches 7 to 16.5 inches
One to four part, continuous, with carbon, fan-folded,
edge-perforated paper forms 3 to 12 inches 7 to 12 inches
One to four part, continuous, carbonless, fan-folded,
edge-perforated paper forms 3 to 12 inches 7 to 16.5 inches
One to six part, continuous, carbonless, fan-folded,
edge-perforated paper forms 3 to 12 inches 7 to 12 inches
Forms with a paper weight of 20 to 100 pounds and a
maximum thickness of 0.025 inches 3 to 12 inches 7 to 16.5 inches
Forms with a paper weight of 18 to 100 pounds and a
maximum thickness of 0.025 inches 3 to 12 inches 7 to 12 inches
Forms with all approved types of interleaf edge attachment
except those using metallic or other hard devices
