Printer component locations – Printronix H-SERIES P7000 User Manual
Page 17
17
Printer Component Locations
Familiarize yourself with the names and locations of the printer components,
shown in Figure 4 before continuing with the rest of the installation
procedures.
Figure 4. Printer Component Locations
Ribbon Spool
Ribbon Hub
Blue Tractor
Lock (2)
Paper Support
Tractor (2)
Vertical
Position Knob
Platen Lever
Ribbon Guide (2)
Ribbon
Splined
Shaft
Platen Stop
Barcode
Hammer Bank
Cover and
Ribbon Mask
Date Code Label
Barcode Sensor
