Fault Messages
161
SHUTL INV PARM* No Shuttle Invalid Parameter.
Firmware error on controller
board. Contact your authorized service
representative.
1
SHUTL OVR SPEED* No The shuttle is oscillating too
rapidly.
Contact your authorized service
representative. 1
SHUTTLE JAM Yes No shuttle movement or
shuttle moving at the wrong
speed. Check for obstruction to shuttle,
a twisted ribbon, or platen lever
closed too tightly. If fault source
is not apparent, contact your
authorized service
representative. 1
SHUTTLE STALL Yes The shuttle is not moving.
See “SHUTTLE JAM” on
page 161. Set the platen lever to match the
thickness of paper, but not too
tightly. Check and adjust the
platen gap. Inspect the ribbon
mask for deformation that snags
and interferes with shuttle
movement. If fault source is not
apparent, contact your
authorized service
representative. 1
SHUTTLE TYPE NOT
SUPPORTED* No The shuttle type was not
detected at power-up or the
shuttle installed in the printer
is not supported by the
firmware. Contact your authorized service
representative.
1
SOFTWARE ERROR*
CYCLE POWER No Application software tried to
perform illegal printer
function, or damaged logic
circuits found on controller
board. Contact your authorized service
representative.
1
SPX FOUND, ERROR:
KEY NOT DETECTED No The controller board does
not have a security key. Contact your authorized service
representative. 1
SPX NOT NEEDED
OPTIONS ENABLED No The user has attempted to
use the SPX to turn on
printer options that are
already enabled. Contact your authorized service
representative.
1
STACK OVERFLOW* No Firmware error on controller
board. Contact your authorized service
representative.
1
STACK UNDERFLOW* No Firmware error on the
controller board. Contact your authorized service
representative. 1
Table 12. LCD Message Troubleshooting Table
Displayed Message
Can User
Correct?
Explanation Solution
