CONTROL REGISTERS
S3F80JB
4-22
P0PND
— Port 0 External Interrupt Pending Register
F2H Set1 Bank0
Bit
Identifier
.7 .6 .5 .4 .3 .2 .1 .0
Reset Value
0 0 0 0 0 0 0 0
Read/Write
R/W R/W R/W R/W R/W R/W R/W R/W
Addressing Mode
Register addressing mode only
.7
P0.7 External Interrupt (INT4) Pending Flag Bit (see Note)
0
No P0.7 external interrupt pending (when read)
1
P0.7 external interrupt is pending (when read)
.6
P0.6 External Interrupt (INT4) Pending Flag Bit
0
No P0.6 external interrupt pending (when read)
1
P0.6 external interrupt is pending (when read)
.5
P0.5 External Interrupt (INT4) Pending Flag Bit
0
No P0.5 external interrupt pending (when read)
1
P0.5 external interrupt is pending (when read)
.4
P0.4 External Interrupt (INT4) Pending Flag Bit
0
No P0.4 external interrupt pending (when read)
1
P0.4 external interrupt is pending (when read)
.3
P0.3 External Interrupt (INT3) Pending Flag Bit
0
No P0.3 external interrupt pending (when read)
1
P0.3 external interrupt is pending (when read)
.2
P0.2 External Interrupt (INT2) Pending Flag Bit
0
No P0.2 external interrupt pending (when read)
1
P0.2 external interrupt is pending (when read)
.1
P0.1 External Interrupt (INT1) Pending Flag Bit
0
No P0.1 external interrupt pending (when read)
1
P0.1 external interrupt is pending (when read)
.0
P0.0 External Interrupt (INT0) Pending Flag Bit
0
No P0.0 external interrupt pending (when read)
1
P0.0 external interrupt is pending (when read)
NOTE: To clear an interrupt pending condition, write a “0” to the appropriate pending flag bit. Writing a “1” to an interrupt
pending flag (P0PND.7–0) has no effect.
