S3F80JB
CONTROL REGISTERS
4-17
IRQ
—
Interrupt
Request
Register
DCH
Set1
Bank0
Bit
Identifier
.7 .6 .5 .4 .3 .2 .1 .0
Reset Value
0 0 0 0 0 0 0 0
Read/Write
R R R R R R R R
Addressing Mode
Register addressing mode only
.7
Level 7 (IRQ7) Request Pending Bit; External Interrupts P0.7–P0.4
0 Not
pending
1 Pending
.6
Level 6 (IRQ6) Request Pending Bit; External Interrupts P0.3–P0.0
0 Not
pending
1 Pending
.5
Level 5 (IRQ5) Request Pending Bit; External Interrupts P2.7–P2.4
0 Not
pending
1 Pending
.4
Level 4 (IRQ4) Request Pending Bit; External Interrupts P2.3–P2.0
0 Not
pending
1 Pending
.3
Level 3 (IRQ3) Request Pending Bit; Timer 2 Match/Capture or Overflow
0 Not
pending
1 Pending
.2
Level 2 (IRQ2) Request Pending Bit; Counter A Interrupt
0 Not
pending
1 Pending
.1
Level 1 (IRQ1) Request Pending Bit; Timer 1 Match/Capture or Overflow
0 Not
pending
1 Pending
.0
Level 0 (IRQ0) Request Pending Bit; Timer 0 Match/Capture or Overflow
0 Not
pending
1
Pending
