S3F80JB

ADDRESSING

MODES

3-11

DIRECT ADDRESS MODE (Continued)

OPCODE

Program Memory

Lower Address Byte

Program
Memory
Address
Used

Upper Address Byte

Sample Instructions:

C,JOB1

; Where JOB1 is a 16-bit immediate address

CALL

DISPLAY

; Where DISPLAY is a 16-bit immediate address

Next OPCODE

Figure 3-11. Direct Addressing for Call and Jump Instructions
