S3F80JB RESET
8-15
HARDWARE RESET VALUES
Tables 8-3 list the reset values for CPU and system registers, peripheral control registers, and peripheral data
registers following a reset operation. The following notation is used to represent reset values:
— A "1" or a "0" shows the reset bit value as logic one or logic zero, respectively.
— An 'x' means that the bit value is undefined after a reset.
— A dash ('–') means that the bit is either not used or not mapped (but a 0 is read from the bit position)
Table 8-3. Set 1, Bank 0 Register Values After Reset
Address Bit Values After Reset Register Name Mnemonic
Dec Hex 7 6 5 4 3 2 1 0
Timer 0 Counter Register T0CNT 208 D0H 0 0 0 0 0 0 0 0
Timer 0 Data Register T0DATA 209 D1H 1 1 1 1 1 1 1 1
Timer 0 Control Register T0CON 210 D2H 0 0 0 0 0 0 0 0
Basic Timer Control Register BTCON 211 D3H 0 0 0 0 0 0 0 0
Clock Control Register CLKCON 212 D4H 0 0 0 0 0 0 0 0
System Flags Register FLAGS 213 D5H x x x x x x 0 0
Register Pointer 0 RP0 214 D6H 1 1 0 0 0
− − −
Register Pointer 1 RP1 215 D7H 1 1 0 0 1
− − −
Location D8H (SPH) is not mapped.
Stack Pointer (Low Byte) SPL 217 D9H x x x x x x x x
Instruction Pointer (High Byte) IPH 218 DAH x x x x x x x x
Instruction Pointer (Low Byte) IPL 219 DBH x x x x x x x x
Interrupt Request Register (Read-
Only) IRQ 220 DCH 0 0 0 0 0 0 0 0
Interrupt Mask Register IMR 221 DDH x x x x x x x x
System Mode Register SYM 222 DEH 0 – – x x x 0 0
Register Page Pointer PP 223 DFH 0 0 0 0 0 0 0 0
Port 0 Data Register P0 224 E0H 0 0 0 0 0 0 0 0
Port 1 Data Register P1 225 E1H 0 0 0 0 0 0 0 0
Port 2 Data Register P2 226 E2H 0 0 0 0 0 0 0 0
Port 3 Data Register P3 227 E3H 0 – 0 0 1 1 0 0
Port 4 Data Register P4 228 E4H 0 0 0 0 0 0 0 0
Port 2 Interrupt Enable Register P2INT 229 E5H 0 0 0 0 0 0 0 0
Port 2 Interrupt Pending Register P2PND 230 E6H 0 0 0 0 0 0 0 0
Port 0 Pull-up Enable Register P0PUR 231 E7H 0 0 0 0 0 0 0 0
Port 0 Control Register (High Byte) P0CONH 232 E8H 0 0 0 0 0 0 0 0
Port 0 Control Register (Low Byte) P0CONL 233 E9H 0 0 0 0 0 0 0 0
