TIMER 1 S3F80JB
11-6
Timer1 Counter High-byte Register (T1CNTH)
F6H, Set 1, Bank 0, R
.7 .6 .5 .4 .3 .2 .1 .0 MSB LSB
Reset Value: 00H
Timer 1 Counter Low-byte Register (T1CNTL)
F7H, Set 1, Bank 0, R
.7 .6 .5 .4 .3 .2 .1 .0 MSB LSB
Reset Value: 00H
Timer 1 Data High-byte Register (T1DATAH)
F8H, Set 1, Bank 0, R/W
.7 .6 .5 .4 .3 .2 .1 .0 MSB LSB
Reset Value: FFH
Timer 1 Data Low-byte Register (T1DATAL)
F9H, Set 1, Bank 0, R/W
.7 .6 .5 .4 .3 .2 .1 .0 MSB LSB
Reset Value: FFH
Figure 11-5. Timer 1 Registers (T1CNTH, T1CNTL, T1DATAH, T1DATAL)
