S3F80JB DEVELOPMENT TOOLS DATA
20-5
NOTE: N.C means No Connection.
N.C
N.C
N.C
P1.5
J2 (for 44-QFP)
P2.3/INT8
P2.4/INT9/CIN0
P3.0/T0PWM/T0CAP/SDAT
P3.1/REM/SCLK
TEST
P2.5/INT9/CIN1
P3.4
P3.5
P2.7/INT9/CIN3
P1.0
P3.2/T0CK
P3.3/T1CAP/T2CAP
P1.2
P1.3
P2.2/INT7
P2.1/INT6
P2.0/INT5
P4.0
P4.1
P4.2
P4.3
P0.7/INT4
P0.6/INT4
P0.5/INT4
P0.4/INT4
P0.3/INT3
P0.2/INT2
P0.1/INT1
P0.0/INT0
P4.4
P4.5
P4.6
P1.7
P1.6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20 44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
P1.4
N.C
N.C
N.C
21 24
P4.7
P1.1
22 23
P2.6/INT9/CIN2
RESET
50-Pin DIP Con
n
ector
V DD
V SS
X OUT
X IN
Figure 20-2. 50-Pin Connector Pin Assignment for TB80JB
Target Board
50
-P
in
DI
P
C
o
n
ne
c
to
r
Target System
50
-P
in
D
IP
C
onn
ec
to
r
J2
1 50
25 26
1 50
25 26
Target Cable for 50-Pin Connector
Figure 20-3. TB80JB Adapter Cable for 44-QFP Package
