Contents
Specifications
6
This chapter defines the MPCBL0001 operating and nonoperating environments. It also documents
the procedures followed to determine the reliability of MPCBL0001.
6.1 Mechanical Specifications
6.1.1 Board Outline
Figure 20 and Figure 21 are annotated illustrations of the MPCBL0001 SBC showing the locations
of major components. The board dimensions are 280 mm x 322.25 mm. The board pitch is 1.2”
(30.48 mm).
Figure 20 is applicable to the following SKU and TA numbers:
• MPCBL0001F04 with TA number C55360-011 or below.
• MPCBL0001N04 with TA number C13354-010 or below.
Figure 21 is applicable to the following SKU and TA numbers:
• MPCBL0001F04 with TA number C55360-014 or below.
• MPCBL0001N04 with TA number C13354-013 or below.
