8.3.8
Fibre Channel Routing (PICMG) Configuration Submenu
To access this submenu, select Advanced on the menu bar, then Fibre Channel Routing (PICMG)
Configuration.
shows how to configure Fibre Channel routing options.
Main
Advanced
Boot
Security
Exit
CPU Configuration
IDE Configuration
Floppy Configuration
SuperIO Configuration
ACPI Configuration
System Management Configuration
Event Logging Configuration
Fibre Channel Routing (PICMG)
Remote Access Configuration
USB Configuration
PCI Configuration
Table 77.
Fibre Channel Routing (PICMG) Submenu
Feature
Options
Description
Fibre Channel A
Front
Back
Disabled
Select Front/Back panel FC A connection.
Fibre Channel B
Front
Back
Disabled
Select Front/Back panel FC B connection.
Actual Fibre Channel Port A State
NA
Display actual Fibre Channel Port A routing.
Actual Fibre Channel Port B State
NA
Display actual Fibre Channel Port B routing.
NOTE: Bold
text indicates default setting.
