Technical Product Specification 121
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
Table 70. Primary IDE Master/Slave Submenu
Feature Options Description
Device Display IDE device.
Vendor Display IDE vendor name.
Size Display IDE device size.
LBA Mode Display IDE LBA Mode status.
Block Mode Display IDE Block Mode status.
PIO Mode Display PIO Mode status.
Async DMA Display Async DMA status.
Ultra DMA Display Ultra DMA-5 status.
S.M.A.R.T Display S.M.A.R.T status.
Type
Not installed
Auto
CDROM
ARMD
Select the type of IDE device connected.
LBA/Large Mode
Disabled
Auto
Disable: Disable LBA ModeAuto: Enable the LBA Mode if the
device supports it and the devices is not already formatted with
LBA Mode disable.
Block (Multi-Sector
Transfer) Disabled
Auto
Disable: The data transfer from and to the device occurs one
sector at a time. Auto: The data transfer from and to the device
occurs multiple sectors at a time if the device supports it.
PIO Mode
Auto
0/1/2/3/4
Select PIO Mode
DMA Mode
Auto
SWDMA0
SWDMA1
SWDMA2
MWDMA0
MWDMA1
MWDMA2
UDMA0
UDMA1
UDMA2
UDMA3
UDMA4
Select DMA Mode
Auto: Auto detected
SWDMAn: SingleWordDMAn
MWDMAn: MultiWordDMAn
UDMAn: UltraDMAn
S.M.A.R.T
Auto
Disabled
Enabled
Enable/Disable S.M.A.R.T.
Auto: Enable S.M.A.R.T if the device supports it.
32 Data Transfer
Disabled
Enabled
Enable/Disable 32-bit Data Transfer.
ARMD Emulation Type
Auto
FloppyHard
Disk
Select ARMD device emulation type by BIOS.
NOTE: Bold text indicates default setting.
