Technical Product Specification 107
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
6.2 Environmental Specifications
The MPCBL0001 SBC meets the board-level specifications as specified in the Intel Environmental
Standards Handbook – Telco Specification Document No. A78805-01. The test methodology is a
combination of Intel and NEBs test requirements with the intent that the product will pass pure
system-level NEBs testing. Intel will not be completing NEBs testing on the SBC. The following
table summarizes environmental limits, both operating and nonoperating.
6.3 Reliability Specifications
6.3.1 Mean Time Between Failure (MTBF) Specifications
Calculation Type: MTBF/FIT Rate
Standard: Telcordia Standard SR-332 Issue 1
Methods: Method I, Case I, Quality Level II
The calculation results were generated using the references and assumptions listed. This report and
its associated calculations supersede all other released MTBF and Failure in Time (FIT)
calculations of earlier report dates. The reported failure rates do not represent catastrophic failure.
Catastrophic failure rates will vary based on application environment and features critical to the
intended function.
Note: Incorporating an optional IDE Hard-disk Drive (HDD) will significantly impact the Reliability
Specifications.
Table 59. Environmental Specifications
Parameter Conditions Detailed Specification
Temperature
(Ambient) Operating (normal) 5 to 40° C
Operating (short term) -5 to 55° C
Storage -40 to 70° C
Airflow Operating 300 linear feet per minute (LFM) minimum
Humidity Operating 10-85% noncondensing
Storage 10-95% noncondensing
Unpackaged Vibration Operating 5 Hz @ 0.01 g2/Hz to 20 Hz @ 0.02g2/Hz (slope up)
20 Hz to 500 Hz @ 0.02 g2/Hz (flat)
Input acceleration = 3.13 gRMS
Storage Not specified in current bluebook.
Shock Unpackaged 50 g
Table 60. Reliability Estimate Data
Failure Rate (FIT)
8,000 Failures in 10 9 hours
MTBF
125,000 Hours
