Technical Product Specification 31
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
09h Event Logging
Disabled BIOS Generated
events BIOS SMI Power On No change
10h Voltage 3.3 VSB ADM 1026 Power On/
Off Exceeds critical
threshold
11h Voltage +5 VSB ADM 1026 Power On/
Off Exceeds critical
threshold
12h +1.8 VSB ADM 1026 Power On/
Off Exceeds critical
threshold
13h V BAT ADM 1026 Power On/
Off Exceeds critical
threshold
14h +1.2 V ADM 1026 Power On Exceeds critical
threshold
15h VTT DDR (+1.25 V) ADM 1026 Power On Exceeds critical
threshold
16h +1.8 V ADM 1026 Power On Exceeds critical
threshold
17h +2.5 V ADM 1026 Power On Exceeds critical
threshold
18h +3.3 V ADM 1026 Power On Exceeds critical
threshold
19h +5 V ADM 1026 Power On Exceeds critical
threshold
30h Temperature Board Temperature ADM 1026 Power On/
Off Exceeds critical
threshold
37h CPU 0 Temperature ADM 1026 Power On Exceeds critical
threshold
38h CPU 1 Temperature ADM 1026 Power On Exceeds critical
threshold
50h Processor CPU 0 Presence ADM 1026 Power On/
Off IERR signal asserted
50h CPU 0 IERR IPMC Power On No change
50h CPU 0 Thermtrip IPMC Power On ThermTrip signal
asserted
50h CPU 0 Non-
Presence ADM 1026 Power On/
Off CPU 0 is detected as
missing
51h CPU 1 Presence ADM 1026 Power On/
Off IERR signal asserted
51h CPU 1 IERR IPMC Power On No change
51h CPU 1 Thermtrip IPMC Power On ThermTrip signal
asserted
54h Boot Error BIOS Main Flash IPMC Power On No change
55h BIOS FRED Flash IPMC Power On No change
56h CPU 0 ProcHot 1 IPMC Power On ProcHot signal asserted
57h CPU1 ProcHot 1 IPMC Power On ProcHot signal asserted
Table 2. Hardware Sensors (Sheet 2 of 3)
Sensor
Number
Sensor Type
Voltage/Signals
Monitored
Monitored
via
Scanning
Enabled
under Power
State
Health LED
(Green to Red)
