116 Technical Product Specification
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
BIOS Setup
8
8.1 Introduction
The BIOS Setup program can be used to view and change the BIOS settings for the computer. The
BIOS Setup program is accessed by pressing the key after the Power-On Self-Test (POST)
begins and before the operating system boot begins.
Table 64 lists the BIOS Setup program menu
features.
Table 65 lists the function keys available for menu screens.
8.2 Main Menu
To access this menu, select Main on the menu bar at the top of the screen.
Table 66 describes the Main menu. This menu reports processor and memory information and is
used for configuring the system date and system time.
Table 64. BIOS Setup Program Menu Bar
Main Advanced Boot Security Exit
Allocates resources
for hardware
components Configures advanced
features available
through the chipset Selects boot
options and power
supply controls Sets passwords
and security
features Saves or discards
changes to Setup
program options
Table 65. BIOS Setup Program Function Keys
BIOS Setup Program
Function Key
Description
< ←> or <→> Selects a different menu screen (moves the cursor left or right).
< ↑ > or <↓> Selects an item (moves the cursor up or down).
Selects a field (not implemented).
Executes command or selects the submenu.
Loads the default configuration values for the current menu.
Saves the current values and exits the BIOS Setup program.
Exits the menu.
Main Advanced Boot Security Exit
