Technical Product Specification
33
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
Table 3.
SEL Events Supported by the MPCBL0001 SBC (Sheet 1 of 4)
Sensor
Type
Sensor
Type Code
Sensor-Specific
Offset (Event
Data 1, Bit 0-3)
Event
Remarks
Reserved
00h
-
Reserved
-
Temperature 01h
-
Temperature
Threshold exceeded for upper critical, upper non-
critical, lower critical and lower non-critical
thresholds. Refer to
Table 4, “Sensor Thresholds for
for sensor
thresholds data.
Voltage
02h
-
Voltage
Voltage exceeded upper critical, upper non-critical,
lower critical and lower non-critical thresholds. Refer
to
for sensor thresholds data.
Processor
07h
00h
IERR
Processor IERR has occurred.
01h
Thermal Trip
Processor thermal trip has occurred.
04h
FRB3/Processor Startup/
Initialization Failure
(CPU did not start)
An FRB3 Timer (30 seconds) was implemented to
detect the failure of the CPUs from booting.
Event data 3 = Last Post 80 code byte
05h
Configuration Error
CPU 0 and CPU 1 are not present.
07h
Processor Presence
Detected
1
09h
Terminator Presence
Detected
1
Power Unit
01h
00h
Power Off/Power On
Normal power off indication. Offset 0 is just a status
indicating that the payload power is off. It does not
generate an event when it is set. (For internal use).
05h
Soft Power Control
Failure (unit did not
respond to request to
turn on)
The Power Unit sensor is used to detect when the
Payload power does not come up when the board is
told to power on.
When the board enters M4 state, the IPMC asserts a
Power Enable line to cause the Payload to power up.
The IPMC then waits for another line that indicates
that the power has come up successfully. If that line
does not assert within 2 seconds, then offset 05h is
asserted on the Power Unit sensor, which generates
an event to notify the Shelf Manager of the failure.
Memory
0Ch
00h
Correctable ECC
Event data 3 = DIMM pair number
00 refers to J8/J9
01 refers to J10/J11
01h
Uncorrectable ECC
Event data 3 = DIMM pair number
00 refers to J8/J9
01 refers to J10/J11
NOTE:
1. These sensor offsets do not generate events, but they are valid offsets when reading the sensor values.
2. Watchdog sensor refers to WDT#1 per
