100

Technical Product Specification

Order #273817

Intel NetStructure

®

MPCBL0001 High Performance Single Board Computer

Contents

NOTE:

MAC Address 2 is an incremental value of MAC Address 1.

Figure 20.

Component Layout (#1)

B3215-03

322.25 mm

350.93 mm

280 mm

IDE Connector

(J24)

PMC Connectors

J16

DIMMs

J18

Fibre Channel

Bar code: MAC Address 1

Bar code: PBA number for
the board

P10

MCH

Gigabit

Ethernet

J23

GP1

GP2

Intel

®

Xeon

™

Processor

Intel

®

Xeon

™

Processor
