120 Technical Product Specification
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
8.3.2.1 Primary IDE Master/Slave Submenu
Hard Disk Write Protect
Disabled
Enabled Enable/Disable Hard Disk device write protection. This is
effective only if the device is accessed through BIOS.
IDE Detect Time Out
0
5
10
15
20
25
30
35
Select the time out value for detecting ATA/ATAPI device(s).
ATA(PI) 80Pin Cable
Detect. Host&Device
Host
Select the mechanism for detecting 80Pin ATA(PI) Cable.
NOTE: Bold text indicates default setting.
Main Advanced Boot Security Exit
CPU Configuration
IDE Configuration
Primary IDE Master/Slave
Floppy Configuration
SuperIO Configuration
ACPI Configuration
System Management Configuration
Event Logging Configuration
Fibre Channel Routing (PICMG)
Remote Access Configuration
USB Configuration
PCI Configuration
Table 69. IDE Configuration Submenu (Sheet 2 of 2)
Feature Options Description
