Intel NetStructure MPCBL0001 - Manual (Page 146)

146 Technical Product Specification
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
Table 97. Flashdos Utility Command Line Options
Command Line Parameter Description
/b [option] bios_image
where possible [option] values are:
• /z - do not clear the CMOS
• /zc - update the CMOS from image
Program a BIOS image to primary firmware hub (FWH0)
/i [bios_image] Display BIOS system information
/r [options] bin_image
where possible [option] values are:
• /aAddress - physical address in hex
• pPage - page number in decimal
• /sSize - image size in decimal
Read the flash image and store to a file
/m Mirror image where all the operational codes and CMOS settings
are copied from FWH0 to FHW1 (redundant BIOS flash bank)
/b cmos_image Backup current CMOS settings to a file
/r cmos_image Restore CMOS settings from a file
/q Force non-interactive mode (assumes “yes” for all prompts)
