Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
Components Illustrated Above:
A - IDE connector (J24)
B - Power mezzanine card + cover
C - PMC connectors
D - Barcode: serial number + PBA version number
E - DIMM banks
F - EMI filter mezzanine
G - Barcode: MAC Address 1 (Note: MAC Address 2 is an incremental value of MAC Address 1. This MAC
Address labeling applies to boards with TA# C13354-015 and C55360-016 (or below).)
Figure 21. Component Layout (#2)
