Page 42
42
Technical Product Specification
Order #273817
Intel NetStructure
®
MPCBL0001 High Performance Single Board Computer
Contents
shows the PCI mapping of the component subsystem of the baseboard.
NOTE:
This table is for MPCBL0001F04 boards. Bus Devices 5 and 7 do not exist for MPCBL0001N04 boards.
Example:
To decode the device and function number from the System Event Log, refer to the following
method.
0144 05/26/04 15:24:42 4023 13 Critical Interrupt 07 PCI PERR 6f [a4 04 08]
•
Event data 1 = a4
Comments: From
, event data 1, bit 3:0 is referring to PCI-PERR
•
Event data 2 = 04.
Comments: From
, event data 2, bit 7:0 is referring to Bus number 4.
•
Event data 3 = 08 = 00001000
Comments: From
, event data 3, bit 7:3 is equivalent to 1 which refers to Device number 1.
Event data 3, bit 2:0 is equivalent to 0 which refers to Function number 0. From
above, the
PCI parity error was on the interface of the Gigabit Ethernet Controller (Port A).
Table 8.
PCI Mapping for Hardware Component Subsystem
Bus
Device
Function
Hardware Component Subsystem
0
0
0
E7501 MCH Bridge
0
0
1
MCH <-> ICH3
0
2
0
82870P2 PCI-X Bridge (PMC and Gigabit Ethernet Controller)
0
3
0
MCH <-> 82870P2 PCI-X Bridge (Fibre Channel Controller)
0
29
0
USB Controller
0
31
1
IDE Interface (hard disk drive)
0
31
3
IPMC Interface
2
29
0
PCI-X Bridge to Gigabit Ethernet Controller
2
1
0
PCI-X Bridge to PMC Card
3
1
0
PMC Card
4
1
0
Gigabit Ethernet Controller (Port A)
4
29
1
Gigabit Ethernet Controller (Port A)
5
29
0
PCI-X Bridge to Fibre Channel Controller
7
1
0
Fibre Channel Controller (Port A)
7
1
1
Fibre Channel Controller (Port B)
0XFF
-
-
PSB (processor-side bus) Error
