Thermals
13
The pressure drop curves versus the flow rate in
represents flow impedance of the slot
This information is provided in accordance with Section 5 of the PICMG 3.0 Specification. It will
aid the system integrator in using the MPCBL0001 SBC in various AdvancedTCA shelves.
Figure 31.
Power vs. Flow Rate
