CONFIG_DATA is a 32-bit read/write window into the PCI configuration space. The portion of
configuration space that is referenced by CONFIG_DATA is determined by the contents of
CONFIG_ADDRESS.
5.2
I/O Address Assignments
I/O port addresses are divided among the on-board devices.These devices include:
•
ICH3
•
ISP2312 Fibre Channel controller
•
82546 Ethernet controller
•
SMSC LPC47B272 SIO
•
MCH
•
IPMC
Please refer to the respective device specifications for specific I/O address usage.
The MCH uses only I/O ports 0xCF8 and 0xCFC for PCI configuration cycle generation. These
registers were shown in
. The P64H2 forwards applicable I/O
transactions to its attached PCI buses. The ISP2312 may be programmed to map its 256-byte bank
of registers to memory and/or I/O space.
lists document references to I/O descriptions. Please refer to
for a list of the referenced documents and their complete titles, revisions, and
document numbers.
Table 55.
Configuration Data Register Bit Assignments
Bit
Description
31:0
Configuration Data Window (CDW)
: If bit 31 of CONFIG_ADDRESS is set to 1, any I/O access to
the CONFIG_DATA register is mapped to configuration space pointed to by the contents of
CONFIG_ADDRESS.
Table 56.
I/O Address Cross-References
Device
Document Title/Number
Section/Page/Table
ICH3
ICH3 EDS
Section 7.3, Table A2 and A3
MCH
E7501 MCH EDS
Section 4.3.5 and 4.3.6
ISP2312
ISP2312 Design Guide
Section 6.6.9 and 6.7
LPC47B272
LPC47B27x Datasheet
(Throughout datasheet)
IPMC
Intel IPMC EDS
Section 4.3.7
82546
Developer’s Manual, OR2941
Section 3.1.1.4
