Symptom or Error

FRUs of the SelectaDock
Sequence of Actions

6XX

1. Before changing any

devices, run the
diagnostic test.

2. FDD external

attachment kit.

3. Diskette drive

assembly.

4. Riser card.

11XX, 12XX

1. Serial devices.

2. Communication cable.

3. Riser card.

17XX

1. Hard disk drive

(2.5-inch ThinkPad
hard disk drive).

2. Main card.

24XX

1. Main card.

2. Riser card.

860X

1. Mouse.

2. External keyboard.

3. Riser card.

I

9990301,

I

9990302

I

9990305

See the hardware
maintenance manual for
the computer.

Not shown above

1. See the hardware

maintenance manual
for the computer.

2. See “Undetermined

Problems” on
page 653.

642

IBM Mobile Systems HMM
