Symptom / Error FRU / Action in Sequence
Serial or parallel port device
problems. 1. Device
2. Device cable
3. System board
External diskette drive does
not work correctly, or
internal diskette drive is not
recognized. 1. Reseat the external
FDD connector.
Note: When reseating
the external FDD
connector,
a. Remove the
connector.
b. Insert the flexible
cable straight until
the white line
aligns with the
edge of the
connector.
c. Replace the
screws of the
connector.
Be careful not to
damage the edge of
the flexible cable
when inserting it into
the connector.
2. External diskette drive
3. Make sure that the
diskette is not
damaged.
ThinkPad 765D (9546), 765L (9547) 445
