1210 Shield Cover (Right, Left)
Diskette Drive or CD-ROM Drive (1020)
Battery Pack (1030)
Hard Disk Drive (1040)
Top Cover (1060)
Keyboard Unit (1070)
LCD Unit (1080)
Front IR and Rear IR (1090)
System Board Assembly (1110)
Upper Shield (1120)
Video Card (1130)
External Diskette Drive Connector (1150)
Module Jack (1160)
Lower Shield (1180)
1 2 : Left lower shield
3 : Right lower shield
Step Size (quantity) Torque
1 M2.5 x 6 mm (1) 3.5 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
486 IBM Mobile Systems HMM
