1060 Top Cover
Diskette Drive/CD-ROM Drive (1020)
Battery Pack (760C/760L/760E/760EL) (1030)
Hard Disk Drive (1040)
Note: When replacing the top cover, be careful not to
damage the resume switch, shown in the figure.
2
4 mm
8 mm,
Flathead 3
4 mm
5 mm, Flathead
Top Cover
1
Resume Switch
Step Size (Quantity) Torque
2 4mm, Nylon (2) 4 kgcm
Note: Make sure you use the correct screw and tighten the
screw to the torque specified. Do not use the screw that you
removed, use a new screw.
