CRS-300 1:10 Redundancy Switch Revision 16
Front Panel Operation MN/CRS300.IOM
7–20
7.8 SELECT: UTILITY
UTILITY: SET-RTC DISPLAY
SWITCH-ID TEST RELAY (ENT)
Select SET-RTC, DISPLAY, SWITCH-ID, or TEST RELAY using the ◄ ► arrow keys, then
press
[ENT] . This submenu permits the User to select from a number of different utility functions,
which are described as follows:
7.8.1 UTILITY: SET- RTC (Set Real-Time Clock)
EDIT REAL TIME CLOCK:
12:00:00 24/04/00 (ENT)
Edit the time and date settings of the real-time clock. Select the character to be edited using the
◄ ► arrow keys, then change the value of the digit using the ▲ ▼ arrow keys.
Note that in accordance with international convention, the date is shown in DAY/MONTH/YEAR
format.
Once the time and date has been edited, the User should press [ENT] .
7.8.2 UTILITY: DISPLAY (Display Brightness)
EDIT DISPLAY BRIGHTNESS:
100% (PRESS ENTER)
Brightness levels of 25%, 50%, 75% or 100% are selectable. Edit the display brightness using the
ST arrow keys. Once the desired brightness has been set, press
[ENT] .
7.8.3 UTILITY: SWITCH-ID
EDIT SWITCH ID: (ENTER)
---- THIS IS A TEST ----
Edit the Switch ID string. Only the bottom line (24 characters) is available. Edit the string by
selecting the cursor position on the bottom line using the ◄ ► arrow keys, then editing the
character in that position using the ST arrow keys.
The following characters are available:
[space] ( ) * + - , . / 0-9 and A-Z
Once the Switch ID string has been edited, press [ENT] .
