CRS-300 1:10 Redundancy Switch
Revision 16
Connector Pinouts
MN/CRS300.IOM
6–10
6.2.9
10/100/1000 Ethernet – RJ-45F Connector (CRS-316/336)
Table 6-12 indicates the pinout for the RJ-45F TMI User Data Interface connector (10/100/1000
Ethernet): J4 on the CRS-316 and CRS-336.
Table 6-12. 10/100/1000 Connector
Pair No.
Pin No.
1
5
4
2
1
2
3
3
6
4
7
8
TMI User Data Interface:
10/100/1000 Ethernet connectors
[For Ethernet Bridge Mode]
