CRS-300 1:10 Redundancy Switch Revision 16
Front Panel Operation MN/CRS300.IOM
7–13
•
If desired, the User can go to Manual mode, switchover the active traffic from the
Redundant Modem onto the Traffic Modem, and then return to Auto mode.
7.5 SELECT: INFO (Information)
The INFO: submenus provide information on the current configuration of the Switch without
risking inadvertent alterations.
INFO: S/N ID SETUP
IF-SWITCH REMCONT MASK
Select S/N, ID, SETUP, IF-SWITCH, REMCONT or MASK using the ◄ ► arrow keys, then
press
[ENT] .
7.5.1 INFO: S/N
SWITCH ID:
-------------------------
This screen displays the unique serial number assigned to this unit by Comtech EF Data. Press
[ENT] or [CLR] to return to the previous menu.
7.5.2 INFO: ID
SWITCH ID:
-------------------------
This screen displays the User-defined Switch ID string, which is entered via the UTILITY:
SWITCH-ID submenu. Press
[ENT] or [CLR] to return to the previous menu.
7.5.3 INFO: SETUP
TM: 1 2 3 4 5 - 7 - 9 10
AUTO:OFF BKUP:05 REST:20
This screen displays some of the settings configured in the CONFIG: OPTIONS menu. Active
Traffic Modems are listed on the top line, with Auto mode and the two Holdoff times listed on
the bottom.
7.5.4 INFO: IF-SWITCH
TRANSPONDER SWITCH IS
ABSENT
This screen displays whether or not a CRS-280(L) IF Transponder Switch is connected to the
CRS-300. When an IF Switch is present, the second line will indicate “
PRESENT ”, and any offline
modem – Redundant or Traffic – will not have its Tx IF muted by the CRS-300.
