Page 87
G0509 & G0509G 16" x 40" Lathe
-85-
parts list
labels & placement
safety labels warn about machine hazards and ways to prevent injury. the owner of this machine
must maintain the original location and readability of the labels on the machine. if any label is
removed or becomes unreadable, replace that label before using the machine again. contact
grizzly at (800) 523-4777 or www.grizzly.com to order new labels.
labels parts list
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
9001 P05099001
THREADING CHART
9011 PLABEL-36
DISCONNECT POWER LABEL
9002 P05099002
GEARBOX PANEL
9012 PLABEL-12
READ MANUAL LABEL
9003 P05099003
SWITCH PANEL
9013 PLABEL-11
SAFETY GLASSES LABEL
9004 P05099004
ENTANGLEMENT SLEEVES LABEL
9014 P05099014
HEADSTOCK PANEL
9005 P05099005
RUBBER MAT
9015 P05099015
DATA LABEL (G0509)
9006 G8589
GRIZZLY LOGO PLATE
P0509G9015
DATA LABEL (G0509G)
9007 P05099007
MODEL NUMBER LABEL (G0509)
9016 P0509G9016
ENTANGLEMENT LABEL (G0509G)
P0509G9007
MODEL NUMBER LABEL (G0509G)
9017 P0509G9017
WARNING TAPE (G0509G)
9008 P05099008
THREAD DIAL CHART
9018 PPAINT-9
GRAY TOUCH-UP PAINT
9009 P05099009
UNLOCK CARRIAGE LABEL
9019 PPAINT-1
GREEN TOUCH-UP PAINT
9010 PLABEL-14
ELECTRICITY LABEL
9010
9006
9007
9009
9011
9013
9004
9012
9017
9016
9015
9001
9002
9014
9008
9003
9005
9019
9018
