Grizzly G0509 - Manual (Page 69)

G0509 & G0509G 16" x 40" Lathe
-67-
REF PART # DESCRIPTION REF PART # DESCRIPTION
2095 PR10M EXT RETAINING RING 22MM 2137 P05092137 COVER
2096 P05092096 GEAR 36-TOOTH 2138 P05092138 SPACER
2097 P05092097 GEAR 24-TOOTH 2139 P05092139 SPACER
2098 P05092098 GEAR 48-TOOTH 2140 P05092140 PLATE
2099 PK34M KEY 5 X 5 X 20MM 2141 P05092141 COVER (G0509)
2100 PR62M EXT RETAINING RING 42MM P0509G2141 COVER (G0509G)
2101 P6204-2RS BALL BEARING 6204 2142 PS79M PHLP HD SCR M3-.5 X 8
2102 P05092102 SHAFT 2143 P05092143 KNURLED NUT M10-1.5
2103 P05092103 KEY 8 X 8 X 115MM 2144 P05092144 STUD M10-1.5 X 85
2104 P05092104 GEAR 26-TOOTH 2145 PN02M HEX NUT M10-1.5
2105 P05092105 SLEEVE 2146 P05092146 LEVER W/HUB ASSEMBLY
2106 P05092106 GEAR 24-TOOTH 2147 P05092147 SPECIAL SCR M12-1.75 X 20
2107 P05092107 GEAR 48-TOOTH 2148 P05092148 BRACKET
2108 P05092108 SHAFT 2149 P05092149 BRACKET
2109 PR09M EXT RETAINING RING 20MM 2150 P05092150 FORK
2110 P05092110 GEAR 36-TOOTH 2151 P05092151 SIGHT GLASS 16MM
2111 P05092111 PACKING 2152 P05092152 LEVER BRACKET
2112 P60052RS BALL BEARING 6005 2153 PK14M KEY 5 X 5 X 18MM
2113 PSB27M CAP SCREW M6-1 X 14 2154 P05092154 RIVET 2 X 5MM
2114 P05092114 COVER 2155 P05092155 PLATE
2115 P05092115 OIL SEAL 2156 P05092156 STEEL BALL 6.5MM
2116 P05092116 CHANGE GEAR 24-TOOTH 2157 P05092157 COMPRESSION SPRING 1 X 5 X 22MM
2117 P05092117 SPACER 2158 PSS14M SET SCREW M8-1.25 X 12
2118 P05092118 O-RING 46 X 3.5MM 2159 P05092159 LEVER SHAFT
2119 P05092119 COVER 2160 P05092160 DOWEL PIN
2120 P6204-2RS BALL BEARING 6204 2161 P05092161 LEVER
2121 P05092121 GEAR 48-TOOTH 2162 P05092162 BRACKET
2122 P05092122 SLEEVE 2163 P05092163 GEAR SHAFT 37-TOOTH
2123 P05092123 BALL BEARING E213 2164 P05092164 LEVER BRACKET
2124 P05092124 COVER 2165 P05092165 COVER
2125 P05092125 PACKING 2166 PK101M KEY 6 X 6 X 14MM
2126 PSB06M CAP SCREW M6-1 X 25 2167 P05092167 SPECIAL ADJUSTING SCREW
2127 P05092127 OIL RING 2168 PSB143M CAP SCREW M10-1.5 X 50 (G0509G)
2128 PSS01M SET SCREW M6-1 X 10 2169 PW04M FLAT WASHER 10MM (G0509G)
2129 P05092129 SPANNER NUT 2170 P0509G2170 HINGE (G0509G)
2130 P05092130 COUNTERWEIGHT 2171 PSB110M CAP SCREW M4-.7 X 6 (G0509G)
2131 P05092131 GEAR 39-TOOTH 2172 P0509G2172 COVER (G0509G)
2132 P05092132 GEAR 54-TOOTH 2173 PSB31M CAP SCREW M8-1.25 X 25 (G0509G)
2133 P05092133 GEAR 47-TOOTH 2174 P0509G2174 SPIDER BOLT 3/8-18 X 1-1/2" (G0509G)
2134 P05092134 GEAR 31-TOOTH 2175 P0509G2175 SPIDER BOLT 3/8-24 X 1/2" (G0509G)
2135 PR13M EXT RETAINING RING 65MM 2176 PN11 HEX NUT 3/8-24 (G0509G)
2136 P05092136 PACKING
headstock parts list
