G0509 & G0509G 16" x 40" Lathe
-53-
motors & switches
figure 81. spindle motor rotation switches
(sQ4, sQ5).
figure 78. Belt cover safety switch (sQ3).
figure 80. Brake switch (sQ1).
figure 77. pump motor (M2) connections.
figure 79. power-in junction box connections.
figure 76. spindle motor (M1) connections.
note:
See
Pages 56 and 57 for wire connections.
