-84-
G0509 & G0509G 16" x 40" Lathe
electrical & coolant system parts list
REF PART # DESCRIPTION REF PART # DESCRIPTION
1100 P05091100 TWO-SPEED SWITCH 8012 P05098012 CONTACTOR SIEMENS 22E, 24V
1302 P05091302 CONTACTOR SIEMENS 40E, 24V 8012-1 P05098012-1 THERMAL RELAY SIEMENS,
1302-1 P05091302-1 THERMAL RELAY SIEMENS, 3UA52 10-16 AMP
0.05-0.32 AMP 8018 P05098018 PUMP
8001 P05098001 POWER LAMP 8019 P05098019 PUMP MOTOR 220V 3-PH
8002 P05098002 PUMP SWITCH 8019-1 P05098019-1 PUMP POWER CORD ASSY
8003 P05098003 EMERGENCY STOP SWITCH 8020 P05098020 CIRCUIT BREAKER SET
8004 P05098004 JOG BUTTON 8021 P05098021 LIMIT SWITCH
8006 P05098006 WORK LAMP ASSEMBLY 8022 P05098022 40-POST TERMINAL BLOCK
8006-1 P05098006-1 BULB 8023 P05098023 TRANSFORMER
8008 P05098008 CUTTING FLUID TUBE KIT 8024 P05098024 MAIN POWER BOX
8009 P0509G8009 TAILSTOCK FLUID TUBE KIT (G0509G) 8026 P05098026 MAIN POWER ON/OFF SWITCH
8010 P05098010 FUSE HOUSING 8027 P05098027 MOTOR ROTATION LIMIT SWITCH
8011 P05098011 FUSE HOUSING
parts list
