-62-
G0509 & G0509G 16" x 40" Lathe
parts list
REF PART # DESCRIPTION REF PART # DESCRIPTION
61 P0509061 TAPER PIN 8 X 85MM 1055 PSB92M CAP SCREW M12-1.75 X 40
79 P0509079 RACK 1056 P05091056 DOWEL PIN 12 X 30MM
1001 PS68M PHLP HD SCR M6-1 X 10 1057 P05091057 COVER
1002 P05091002 COVER (G0509) 1058 P05091058 GUARD ASSEMBLY
P0509G1002 COVER (G0509G) 1059 P05091059 GAP BLOCK
1003 P05091003 STAND 1060 PSB70M CAP SCREW M10-1.5 X 45
1004 P05091004 PULLEY 1062 PN03M HEX NUT M8-1.25
1005 P05091005 BELT BRAKE 1063 PSB05M CAP SCREW M8-1.25 X 50
1006 PS68M PHLP HD SCR M6-1 X 10 1064 P05091064 RACK
1007 PS68M PHLP HD SCR M6-1 X 10 1065 P05091065 CLUTCH
1008 P05091008 SWITCH SEAT 1066 P05091066 STEEL BALL 8MM
1009 PN04M HEX NUT M4-.7 1067 P05091067 TAPER PIN 5 X 45MM
1010 PSB21M CAP SCREW M4-.7 X 30 1068 P05091068 COMPRESSION SPRING 1.2 X 6 X 46MM
1011 P05091011 LIMIT SWITCH 1069 P05091069 SPECIAL SCR M10-1.5 X 10
1012 P05091012 MOTOR SEAT BRACKET 1070 P05091070 SLEEVE
1013 P05091013 SHAFT 1071 P05091071 DOWEL PIN
1014 P05091014 CAM 1072 P05091072 THRUST WASHER
1015 P05091015 BRAKE ARM 1073 PR19M EXT RETAINING RING 28MM
1016 P05091016 SHAFT 1074 PK08M KEY 5 X 5 X 16MM
1017 P05091017 SPRING 1075 P05091075 COMPRESSION SPRING 1.8 X 2.5 X 55
1018 P05091018 SHAFT 1076 P05091076 COVER
1019 P05091019 MOTOR SEAT 1077 PSB07M CAP SCREW M6-1 X 30
1020 PB31M HEX BOLT M10-1.5 X 40 1078 PRP08M ROLL PIN 6 X 30MM
1021 PLW06M LOCK WASHER 10MM 1080 P05091080 ROD
1022 PLW10M LOCK WASHER 16MM 1081 P05091081 FEED ROD
1023 PN13M HEX NUT M16-2 1082 P05091082 LEAD SCREW
1024 P05091024 THREADED STUD M16-2 X 150 1083 P05091083 SLEEVE
1025 P05091025 SPECIAL WASHER 1084 PSS02M SET SCREW M6-1 X 6
1026 P05091026 MOTOR 1085 PSB40M CAP SCREW M8-1.25 X 35
1026-1 P05091026-1 MOTOR FAN COVER 1086 P05091086 SLEEVE
1026-2 P05091026-2 MOTOR FAN 1087 P05091087 TAPER PIN 6 X 50MM
1027 P05091027 COVER (G0509) 1088 P8203 THRUST BEARING 8203
P0509G1027 COVER (G0509G) 1089 P05091089 SLEEVE
1028 PSB04M CAP SCREW M6-1 X 10 1090 PSS03M SET SCREW M6-1 X 8
1029 P05091029 COVER 1091 P05091091 PLUG
1030 P05091030 SLEEVE 1092 P05091092 END PLAY ADJUSTMENT NUT
1031 P05091031 BRACKET 1093 P05091093 STEEL BALL 9.5MM
1032 P05091032 ARM 1094 P05091094 COMPRESSION SPRING 1 X 9 X 20MM
1033 P05091033 BRAKE PEDAL 1095 PSB68M CAP SCREW M6-1 X 8
1042 PSB52M CAP SCREW M8-1.25 X 10 1096 P05091096 BRACKET
1043 P05091043 CLEVIS PIN 7.5 X 25MM 1097 P05091097 STUD M12-1.75 X 100
1044 PEC09M E-CLIP 6MM 1098 PN09M HEX NUT M12-1.75
1045 P05091045 ROD 1099 PW06M FLAT WASHER 12MM
1046 P05091046 LEVER 1100 P05091100 BED
1049 P05091049 KNURLED THUMB NUT 1101 PB24M HEX BOLT M12-1.75 X 45
1050 P05091050 MOUNTING STUD 1102 PLW05M LOCK WASHER 12MM
1051 PN02M HEX NUT M10-1.5 1103 P0509G1103 BUFFER BUMPER
1052 PB35M HEX BOLT M12-1.75 X 40
frame, Ways, & stand parts list
