G0509 & G0509G 16" x 40" Lathe
-71-
parts list
gearbox parts list
REF PART # DESCRIPTION REF PART # DESCRIPTION
448 P05090448 LEVER 3054 P05093054 FORK
3001 PEC06M E-CLIP 20MM 3055 P05093055 FORK
3002 P05093002 ROLLER BEARING 943/20 3056 PSB01M CAP SCREW M6-1 X 16
3003 P05093003 OIL SEAL 3057 PLW03M LOCK WASHER 6MM
3004 P05093004 SHAFT 3058 P05093058 FORK
3005 PSB11M CAP SCREW M8-1.25 X 16 3059 P05093059 CASTING
3006 P05093006 WIDE WASHER 3060 PSB15M CAP SCREW M5-.8 X 20
3007 P05093007 KEY 8 X 8 X 28MM 3061 P05093061 FORK
3008 P05093008 SLEEVE 3062 P05093062 LEVER
3009 P05093009 CHANGE GEAR 57-TOOTH 3063 P05093063 COMPRESSION SPRING 1 X 8 X 32
3010 P05093010 SHAFT 3064 P05093064 LEVER
3011 PN32M HEX NUT M14-2 3065 P05093065 SELECTOR
3012 P05093012 SLEEVE 3067 P05093067 COVER
3013 P05093013 WIDE WASHER 14MM 3068 P05093068 O-RING 30 X 2.65MM
3014 P05093014 ROLLER BEARING 160105 3069 P05093069 COVER
3015 PR25M INT RETAINING RING 47MM 3070 PSB38M CAP SCREW M5-.8 X 25
3017 P05093017 CHANGE GEAR 44/52-TOOTH 3071 P05093071 BRACKET
3018 P05093018 BELLCRANK SWING ARM 3072 P05093072 O-RING 38.7 X 2.65MM
3019 PSB01M CAP SCREW M6-1 X 16 3073 PSB01M CAP SCREW M6-1 X 16
3020 P05093020 BRACKET 3074 P05093074 BRACKET
3021 P05093021 THRUST WASHER 3075 PSS02M SET SCREW M6-1 X 6
3022 P05093022 GEAR 39/20-TOOTH 3076 P05093076 CAP SCREW
3023 P05093023 BALL BEARING 7000104 3077 P05093077 STEEL BALL 6MM
3024 P05093024 SHAFT 3078 P05093078 FORK
3025 P05093025 GEAR 38-TOOTH 3079 P05093079 FORK
3026 P05093026 GEAR 22-TOOTH 3080 P05093080 FORK
3027 P05093027 GEAR 19-TOOTH 3081 P05093081 FORK
3028 P05093028 GEAR 20-TOOTH 3082 P05093082 DRIVE PLATE
3029 P05093029 GEAR 24-TOOTH 3083 P05093083 COMPRESSION SPRING .8 X 5 X 17
3030 P05093030 GEAR 23-TOOTH 3084 P05093084 TOP PLATE
3031 P05093031 GEAR 27-TOOTH 3085 P05093085 SLEEVE
3032 P05093032 GEAR 23/19-TOOTH 3086 PSB48M CAP SCREW M6-1 X 35
3033 P05093033 GEAR 24-TOOTH 3087 P05093087 PLUG
3034 P05093034 GEAR 28-TOOTH 3088 P05093088 OIL INLET PIPE
3035 P05093035 GEAR 26-TOOTH 3089 PSB127M CAP SCREW M6-1 X 65
3036 P05093036 GEAR 38-TOOTH 3090 P05093090 SIGHT GLASS 20MM
3037 P05093037 THRUST WASHER 3091 PS05M PHLP HD SCR M5-.8 X 8
3038 P203 BALL BEARING 203 3094 P05093094 PLATE
3039 PR23M INT RETAINING RING 40MM 3095 P05093095 PLATE
3040 P05093040 CLUTCH 3096 P05093096 LEVER
3041 PR02M EXT RETAINING RING 14MM 3097 PSB42M CAP SCREW M6-1 X 85
3042 P05093042 CLUTCH GEAR 3098 P05093098 PACKING
3043 P05093043 SHAFT 3099 P05093099 PACKING
3044 P05093044 THRUST WASHER 3100 P05093100 THRUST WASHER
3045 P05093045 PACKING 3101 P05093101 SHAFT
3046 P05093046 COVER 3102 P05093102 GEAR 30/19-TOOTH
3047 P05093047 THRUST WASHER 3103 P05093103 THRUST WASHER
3049 PR18M EXT RETAINING RING 17MM 3104 PK08M KEY 5 X 5 X 16MM
3050 P05093050 KEY 3 X 3 X 12MM 3105 P05093105 GEAR 22-TOOTH
3051 P05093051 CAM 3106 P05093106 SHAFT
3052 P05093052 BRACKET 3107 PR11M EXT RETAINING RING 25MM
3053 P05093053 SHAFT
