Grizzly G0509 - Manual (Page 68)

-66-
G0509 & G0509G 16" x 40" Lathe
parts list
REF PART # DESCRIPTION REF PART # DESCRIPTION
2001 P05092001 HEX NUT M30-1.5 2048 P05092048 SHAFT
2002 P05092002 TOOTHED LOCK WASHER 30MM 2049 P05092049 LEVER
2003 PK41M KEY 8 X 8 X 40MM 2050 P05092050 FORK
2004 P05092004 SHAFT 2051 P05092051 O-RING 14 X 2.65MM
2005 P05092005 PULLEY 2052 P05092052 PLUG
2006 P05092006 SPACER 2053 PSB07M CAP SCREW M6-1 X 30
2007 P05092007 OIL SEAL 2054 P05092054 OIL PLUG
2008 P05092008 O-RING 36 X 3.5MM 2055 P05092055 FORK
2009 P05092009 BEARING COVER 2056 P05092056 LEVER
2010 P05092010 PACKING 2057 P05092057 STEEL BALL 10MM
2011 PSB29M CAP SCREW M6-1 X 40 2058 P05092058 COMPRESSION SPRING 0.9 X 9 X 35MM
2012 P6206ZZ BALL BEARING 6206 2059 P05092059 BRACKET
2013 P05092013 KEY 8 X 8 X 50MM 2060 PSS01M SET SCREW M6-1 X 10
2014 P05092014 GEAR 38-TOOTH 2061 P05092061 O-RING 28 X 3.1MM
2015 P05092015 GEAR 33-TOOTH 2062 P05092062 COVER
2016 P05092016 SLEEVE 2063 P05092063 LEVER HUB
2017 P05092017 GEAR 23-TOOTH 2064 P05092064 O-RING 10 X 2.65MM
2018 P05092018 GEAR 33-TOOTH 2066 P05092066 LEVER
2019 P6205ZZ BALL BEARING 6205ZZ 2067 P05092067 LEVER HUB
2020 PR11M EXT RETAINING RING 25MM 2068 PR04M EXT RETAINING RING 6MM
2021 PSS34M SET SCREW M5-.8 X 16 2069 PK05M KEY 4 X 4 X 10MM
2022 P05092022 PLUG 2070 PSB26M CAP SCREW M6-1 X 12
2023 P05092023 BALL BEARING E206 (G0509) 2071 P05092071 PLATE
2024 PR15M EXT RETAINING RING 30MM 2072 P05092072 SHAFT
2025 P05092025 SHAFT 2073 P05092073 COMPRESSION SPRING 0.9 X 9 X 40MM
2026 PR56M EXT RETAINING RING 45MM 2074 P05092074 LEVER
2027 PK136M KEY 8 X 8 X 30MM 2075 P05092075 BRACKET
2028 P05092028 GEAR 60-TOOTH 2076 P05092076 FORK
2029 P05092029 GEAR 21-TOOTH 2077 PSS03M SET SCREW M6-1 X 8
2030 P05092030 PLUG 2078 P05092078 SPANNER NUT
2031 P05092031 O-RING 19 X 2.65MM 2079 P05092079 LEAD PLUG
2032 P6305ZZ BALL BEARING 6305ZZ 2080 P05092080 TAPERED ROLLER BEARING
2033 P05092033 EXT RETAINING RING 62MM 2081 P05092081 EXT RETAINING RING 75MM
2034 P05092034 COVER 2082 P05092082 GEAR 43-TOOTH
2035 P05092035 O-RING 56 X 3.5MM 2083 P05092083 GEAR 82-TOOTH
2036 P05092036 PLATE 2084 P05092084 KEY 8 X 8 X 60MM
2037 P05092037 FLAT HD SCR M3-.5 X 15 2085 P05092085 TAPERED ROLLER BEARING
2038 P05092038 PACKING 2086 P05092086 COVER
2039 P05092039 COVER 2087 P05092087 PACKING
2040 P05092040 CASTING 2088 P05092088 CAM LOCK
2041 PRP05M ROLL PIN 5 X 30MM 2089 P05092089 COMPRESSION SPRING
2042 P05092042 GEAR 43-TOOTH 2090 P05092090 SPECIAL CAP SCREW
2043 P05092043 BRACKET 2091 P05092091 SPINDLE D1-6 (G0509)
2044 P05092044 SLEEVE P0509G2091 SPINDLE D1-6 (G0509G)
2045 PSS01M SET SCREW M6-1 X 10 2092 P05092092 CAM LOCK STUD
2046 P05092046 PLUG 2093 P05092093 SHAFT
2047 P05092047 COVER 2094 P05092094 SPACER
headstock parts list
