Grizzly G0509 - Manual (Page 74)

-72-
G0509 & G0509G 16" x 40" Lathe
gearbox parts list
REF PART # DESCRIPTION REF PART # DESCRIPTION
3108 P05093108 GEAR 22-TOOTH 3134 PRP56M ROLL PIN 4 X 25mm
3109 P05093109 GEAR 22-TOOTH 3135 P05093135 PACKING
3110 P05093110 GEAR 33-TOOTH 3136 P05093136 LEVER
3111 P05093111 GEAR 22-TOOTH 3137 P05093083 COMPRESSION SPRING
3112 P05093112 THRUST WASHER 3138 P05093138 SELECTOR BAR
3113 P05093113 SPECIAL NUT 3139 P05093139 SHAFT
3114 PSS07M SET SCREW M5-.8 X 5 3140 P05093140 COVER
3115 P05093115 SHAFT 3141 P05093141 PLATE
3116 PR10M EXT RETAINING RING 22MM 3142 P05093142 PLATE
3117 PK15M KEY 5 X 5 X 35MM 3143 P05093143 FORK
3118 P05093118 GEAR 33-TOOTH 3144 PRP70M ROLL PIN 5 X 18MM
3119 P05093119 GEAR 36/20-TOOTH 3145 PRP44M ROLL PIN 3 X 10MM
3120 P05093120 ROLLER BEARING 101 3146 P05093146 FORK
3121 PR03M EXT RETAINING RING 12MM 3147 P05093147 TAPER PIN 8 X 90MM
3122 P05093122 BRACKET 3148 P05093148 FORK
3123 P05093123 OIL SEAL 3149 P05093149 PLATE
3124 P8105 THRUST BEARING 8105 3150 PRP37M ROLL PIN 3 X 14MM
3125 P05093125 BRACKET 3151 P05093151 FORK
3126 P05093126 THRUST WASHER 3152 PSB35M CAP SCREW M8-1.25 X 60
3127 PSS20M SET SCREW M8-1.25 X 8 3153 P05093153 PACKING
3128 PR39M EXT RETAINING RING 8MM 3154 PS07M PHLP HD SCR M4-.7 X 8
3129 P05093083 COMPRESSION SPRING 3155 PSB33M CAP SCREW M5-.8 X 12
3130 P05092156 STEEL BALL 6.5MM 3156 P05093156 WASHER
3131 P05093131 LEVER 3157 P05093157 SLEEVE
3132 P05093132 LEVER 3158 P05093158 O-RING 16 X 2.65MM
3133 P05093133 FORK 3159 P05093159 LEVER
