G0509 & G0509G 16" x 40" Lathe
The information contained herein is deemed accurate as of 5/24/2007 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 2 OF 3
Model G0509
Main Specifications:
Operation Info
Swing Over Bed......................................................................................................................................... 16 in.
Dist Between Centers.................................................................................................................................40 in.
Swing Over Cross Slide............................................................................................................................. 10 in.
Swing Over Saddle................................................................................................................................ 9-7/8 in.
Swing Over Gap.........................................................................................................................................22 in.
Max Tool Bit Size...................................................................................................................................... 3/4 in.
Compound Travel...................................................................................................................................5-1/2 in.
Carriage Travel...........................................................................................................................................33 in.
Cross Slide Travel..................................................................................................................................8-1/2 in.
Headstock Info
Spindle Bore.................................................................................................................................................2 in.
Spindle Taper.............................................................................................................................................MT#6
No Of Spindle Speeds.....................................................................................................................................16
Range Of Spindle Speeds.......................................................................................................... 45 - 1800 RPM
Spindle Type.............................................................................................................................. D1-6 Cam Lock
Spindle Bearings......................................................................................................................... Tapered Roller
Tailstock Info
Tailstock Travel......................................................................................................................................4-3/4 in.
Tailstock Taper.......................................................................................................................................... MT#4
Tailstock Barrel Diameter............................................................................................................................. 2 in.
Threading Info
No Of Inch Threads.........................................................................................................................................45
Range Of Inch Threads.......................................................................................................................2 - 72 TPI
Range Of Longitudinal Feeds................................................................................................... 0.002 - 0.067 in.
No Of Longitudinal Feeds............................................................................................................................... 17
No Of Cross Feeds......................................................................................................................................... 17
Range Of Cross Feeds.................................................................................................... 0.0011 - 0.038 in./rev.
No Of Metric Threads......................................................................................................................................39
Range Of Metric Threads.................................................................................................................0.2 - 14 mm
No Of Modular Threads...................................................................................................................................18
Range Of Modular Threads............................................................................................................. 0.3 - 3.5 MP
No Of Diametrical Threads..............................................................................................................................21
Range Of Diametrical Threads............................................................................................................ 8 - 44 DP
Dimensions
Bed Width...................................................................................................................................................10 in.
Leadscrew TPI.................................................................................................................................................. 4
Leadscrew Length......................................................................................................................................54 in.
Steady Rest Capacity.............................................................................................................................4-7/8 in.
Follow Rest Capacity............................................................................................................................. 2-7/8 in.
Faceplate Size............................................................................................................................................14 in.
Leadscrew Diameter............................................................................................................................. 1.120 in.
Feed Rod Diameter...............................................................................................................................0.745 in.
Floor To Center Height...............................................................................................................................45 in.
Construction
Base Construction................................................................................................................................ Cast Iron
Headstock Construction....................................................................................................................... Cast Iron
Headstock Gears Construction....................................................................................... Flame Hardened Steel
Bed Construction..................................................................................................Induction Hardened Cast Iron
Body Construction................................................................................................................................ Cast Iron
Stand Construction...............................................................................................................................Cast Iron
Paint..........................................................................................................................................................Epoxy
