G0509 & G0509G 16" x 40" Lathe
-39-
g7038z—boring bar
g7040—carbide inserts for steel (5 pk)
g7048—carbide inserts for cast iron (5 pk)
figure 47. g7038z Boring Bar.
g7030—threading tool holder
g7041—carbide inserts for steel (5 pk)
g7049—carbide inserts for cast iron (5 pk)
figure 48. g7030 threading tool holder.
g7033—internal threading tool holder
g7042—carbide inserts for steel (5 pk)
g7050—carbide inserts for cast iron (5 pk)
figure 49. g7033 int. threading tool holder.
Quick change tool holders
All models below are series 300
g5708—boring bar holder, 3 ⁄
4
" & 1" bar
g5711—parting tool holder, 3 ⁄
4
" tool
g5712—Knurling tool holder, 1 ⁄
2
"~ 3 ⁄
4
" tool
g5710—morse taper holder, mt#4 taper
g5707—turning/boring holder, 1 ⁄
2
"~ 3 ⁄
4
" bits
g5706—turning holders, 1 ⁄
2
"~ 3 ⁄
4
" bits
figure 44. series 300 quick change tool holders.
g5708 g5711 g5712
g5710 g5707 g5706
h5787—mt#4 x 5" bull nose rolling center
Built with precision sealed bearings, designed for
heavy-duty use on hollow workpieces.
figure 45. Mt#4 bull nose rolling centers.
g9889—mt#4 long nose precision center
provides critical tool clearance. Adjustable thrust
bearings, 60° tip and 30° clearance relief angle.
figure 46. Mt#4 long nose Center
