Figure 22: Locking the BX920 S1 server blade
Ê Push the release lever up until it clicks into place under the locking lever (1).
Removal is carried out in reverse order.
Installing a single height / double width Blade
The following describes how to install a BX960 S1 server blade. This server
blade occupies 2 bays one upon the other in the BX900 S1 system unit.
1
