112 Operating Manual BX900 S1
Hot-plug components
©
c
o gn
itas
. G
es
el
ls
ch
ft f
ür
T
ec
h
ni
k-
Do
ku
m
en
tat
io
n
m
bH
2
01
1
P
fa
d:
C
:\P
rogr
am
m
e \F
CT
\t im
_ap
p\
tim
_l
oc
al
\w
ork
\W
A
LT
E
R
\O
B
J_
DO
K U
-4
95
3-0
07
.fm
8.2.7 Connection Blade Infiniband Switch 40 Gb 18/18
The Connection Blade Infiniband Switch 40Gb 18/18 provides the following
connections:
– 18 internal 40-Gbit Infiniband ports to the server blades
– 18 external 40-Gbit Infiniband connections through QSFP modules
This connection blade can be used in slots CB 3/4, CB 5/6 and CB 7/8, see
figure "Connection blade slots" on page 117 . It only supports server blades that
are fitted with an Infiniband mezzanine card. For more information, see the
operating manuals for the relevant server blades.
Ports and LEDs
Figure 40: Connection Blade Infiniband Switch 40 Gb 18/18
1 Status indicator (green/yellow)
Lights up green: Power supply is supplied to the connection blade
Flashes yellow: Switch error
3 4
1
2
A
