70 Operating Manual BX900 S1
Installation and operation
©
c
o gn
itas
. G
es
el
ls
ch
ft f
ür
T
ec
h
ni
k-
Do
ku
m
en
tat
io
n
m
bH
2
01
1
P
fa
d:
C
:\P
rogr
am
m
e \F
CT
\t im
_ap
p\
tim
_l
oc
al
\w
ork
\W
A
LT
E
R
\O
B
J_
DO
K U
-4
95
0-0
07
.fm
5.3 Configuring management blades
The two redundant management blades form the central interface for
administration of the system unit and all components therein. This section
explains how to do the initial configuration of the management blades.
For more information on administration of the blade server, see the manual
"PRIMERGY BX900 Blade Server Systems ServerView Management Blade S1
User Interface Description".
Initial configuration with the Base Configuration Wizard
Ê
Make sure that the hardware installation of the system unit as described in
chapter
"Installing the hardware" on page 39 .
Ê Press the On/Off button on the ServerView local service panel (position 4 in
figure 14 on page 60 ) to switch on the system unit.
The management blade boots and the ServerView local service panel shows
the start menu of the Base Configuration Wizard.
Figure 19: Base Configuration Wizard start menu
Ê
Select YES with the navigation buttons and press the button to start the
wizard.
The NO button closes the Base Configuration Wizard, and the Health Status
Overview menu is displayed.
