Further information
For more detailed information and additional possible configurations, see the
manuals "PRIMERGY BX900 Blade Server Systems – Ethernet Connection
Blade Module IBP Version – User’s Guide", "PRIMERGY BX900 Blade Server
Systems – Ethernet Connection Blade Module Switch Version – User’s Guide"
and " ス イ ッ チ ブ レー ド (1 Gbps 36/8+2, 1 Gbps 36/12) 取扱説明書 " (for the
japanese market).
Rack (R) BX900 (Z)
Fitting variants of connection blades
a b c d e f
4 racks, 4 BX900s R1 Z1 2
R2 Z2 2
R3 Z3 2
R4 Z4 2
