Hot-plug components
Installing a single height / single width Blade
The following describes how to install a BX920 S1 server blade. Storage blades
are installed in the same way.
Figure 21: Installing the BX920 S1 server blade
Ê
Undo the locking mechanism of the release lever (1).
Ê
Open the release lever (2).
Ê
Push the server blade as far as possible into the empty slot (3).
1
2
3
