Fostex PD-6 - Manual (Page 95)

93
PD-6 DVD Location Recorder (Chapter 7: Setup mode)
-20dB
-18dB
Option Comment
When the reference level is set to “-20 dB”. When the reference level is set to “-18 dB”.
0 to 9 seconds
Infinity
Option Comment
Reference level setting (Reference level)
The “Reference level” menu selects the input reference level.
With the “Ref. level” menu, you can select “-20 dB” or “-18 dB”.
flashing
flashing
Sets the input reference level to -20 dB (default setting).
Sets the input reference level to -18 dB.
The reference level setting is reflected to the level meter on the display.
Peak hold time setting (Peak hold)
The “Peak hold” menu sets the peak hold time.
With the “Peak hold” menu, you can set the peak hold time between 0 and 9
seconds (or infinity).
You can set the time in one second steps (the default setting is 3 seconds).
The infinity setting keeps holding the peak indication until pressing the
[CLEAR] key.
