142
PD-6 DVD Location Recorder (Chapter 11: Specifications)
*0 dBu=0.775 Vrms, 0 dBV=1 Vrms.
Reference level : -18 dB/-20 dB (default: -18 dB, selectable in the "Ref. Level" menu of the Setup
mode)
Inputs/Outputs
ANALOG MIC/LINE IN (CH 1 through 6)
• Connectors : XLR-3-31 type (balanced, pin 2: hot)
• Input impedance : More than 10k Ω
• Input level : -30 ~ +4dBu (+/-5dB)
• Maximum input level : +24 dBu (+41 dBu at the prefader stage)
• Input impedance : More than 10k Ω
• Input level : -60 ~ -26dBu (+/-5dB)
• Maximum input level : -40 dBu (-23dBu at the prefader stage)
ANALOG LINE OUT (TR 1 through TR 6)
• Connectors : XLR-3-32 type (balanced, pin 2: hot)
• Output load impedance : More than 10k Ω
• Reference output level : +4 dBu
• Maximum output level : +24 dBu
HEADPHONE OUTPUT (SOLO or STEREO/MONO: 1+2, MS, 3/5+4/6, 1/3/5+2/4/6, 3/5+2/4/6, 1/
3+2/4, ST, AUX IN, ST. BUS)
• Connector : 6mm dia stereo phone jack
• Applicable load impedance : More than 32 Ω
• Maximum output level : 200 mW (at 32 Ω )
DIGITAL I/O (for channels 1 through 6)
• Connector : D-sub 25-pin (auto software selection)
• Format
: IEC 60958 (S/P DIF) or IEC 60958 (AES/EBU),
auto selection
: IEC 60958 (S/P DIF) or IEC 60958 (AES/EBU),
The format of an output signal is selected in
the Setup mode.
TIME CODE INPUT
• Connector : XLR-3-31 type (balanced, pin 2: hot)
• Format : SMPTE/EBU
• Reference input level : 2V p-p
• Input impedance : More than 20k Ω
• Minimum input level : 0.25V p-p
TIME CODE OUTPUT
• Connector : XLR-3-32 type (balanced, pin 2: hot)
• Format : SMPTE/EBU
• Reference output : 2V p-p
• Output impedance : Less than 1k Ω
• Output load impedance : More than 600 Ω
VIDEO/WORD INPUT
• Connector : BNC type (auto software selection)
• Refernce input level : TTL level (with 75 Ω termination switch)
* The signal type (word or video) is automatically detected.
